12m Depth Sand Dredging Boat With Cutter Head Pond Dredging Equipment

Name: 12m Depth Sand Dredging Boat With Cutter Head Pond Dredging Equipment
Brand: Jin Meng
Price: 100000 USD

Brand Name : Jin Meng

Model Number : JMD350

Place Of Origin : China

Certification : ISO

MOQ : 1 set

Price : $100000-$300000

Payment Terms : T/T

Supply Ability : 30sets/year

Delivery Time : 30days

Packaging Details : Containers

Diesel Engine Brand : WEICHAI/CUMMINS

Suction Pipe Diameter : 400mm

Dredging Pump : Centrifugal Slurry Dredging Pump

Spud Length : 10-30m

Dredging Depth : 8-12m

Design Discharge Distance : 1,500m

Color : Custom Made

Customize : Accepted

Name : JMD350 cutter head sand dredger

Type : River sand cutter suction dredger

Contact Now

12m Depth Sand Dredger With Cutter Head For Pond Dredging

Product Specifications

Diesel Engine Brand	WEICHAI/CUMMINS
Suction Pipe Diameter	400mm
Dredging Pump	Centrifugal Slurry Dredging Pump
Spud Length	10-30m
Dredging Depth	8-12m
Design Discharge Distance	1,500m
Color	Custom Made
Customize	Accepted
Model	JMD350 cutter head sand dredger
Type	River sand cutter suction dredger

Product Overview

This professional-grade sand suction dredger is designed for efficient dredging, excavation, and mining operations. The JMD350 model features exceptional customization options including color choices and adjustable spud lengths (10-30m) to suit various project requirements.

Key Features

400mm suction pipe diameter for efficient material handling
1,500m design discharge distance
Powerful diesel engine (WEICHAI/CUMMINS)
14-inch discharge diameter
High-performance centrifugal slurry dredging pump
Custom color options available

Technical Parameters

Dredging Pump	Dia. Discharge pipe: 350mm
Head	55m
Max. Working capacity	260m³/h
Discharge distance	1500m
Dredging depth	8m
Diesel Engine	522KW \| Cummins
Generator	12KW \| WEICHIA
Total power	534KW
Oil Consumption	80L/H
Hull Dimensions	23m × 5.2m × 1.5m
Hydraulic System	VICKERS America (Joint-venture)
Hydraulic Motor	Italy SAI technology (Joint-venture)
Valves	REXROTH Germany (Joint-venture)
Operating system	SIEMENS PLC (Imported from Germany)
Cutter Head	Φ1300mm crown-like, 60KW power

Applications

The JMD350 cutter head sand dredger is ideal for various dredging projects including:

River and lake dredging
Coastal area maintenance
Harbor dredging
Land reclamation
Waterway maintenance

Support and Services

Our comprehensive support package includes technical assistance, operator training programs, and maintenance services to ensure optimal performance and minimal downtime.

Packing and Shipping

The dredger is securely packed in wooden crates for safe transportation. We offer worldwide shipping with costs varying by destination and shipping method.
