Sea Bed Desilting Cutter Sand Dredger for Salty Water & Lake Dredging
Product Specifications
| Name | Cutter suction sand dredger |
| Side Plate Thickness | 14mm |
| Cutter Blade Quantity | 5-6 Pieces Crown Type |
| Work Site | River, Lake, Sea, Pond |
| Discharge Distance | 500-2000m |
| Maximum Dredging Depth | 18 meters |
| Usage | Dredging Works And Dredging Project |
| Discharge Pipe Diameter | 650 mm |
| Dredging Pump | Centrifugal slurry dredging pump |
| Spud carriage | Equipped |
About Weifang Jin Meng Dredger Co., Ltd.
Weifang Jin Meng Dredger Co., Ltd., located in Qingzhou, Weifang City, Shandong Province, China, has specialized in cutter suction sand dredger manufacturing since 2000. Our dredgers offer competitive pricing and serve markets across Africa, the Middle East, Southeast Asia, South America, and North America.
Product Description
Our cutter suction sand dredgers are available in self-propelled or non-self-propelled configurations with portable designs. The hull features a dismantle and box-like structure for easy assembly at worksites and transportation via road, rail, or container. Power systems can be customized as electric or diesel engine configurations.
JMD650 26inch Cutter Suction Sand Dredger Technical Specifications
Dredging Pump: Dia. Discharge pipe 650mm
Head: 65m
Max. Working capacity: 1100m³/h
Discharge distance: 4000m
Dredging depth: 18m
Diesel Engine: 1885KW Mitsubishi
Hydraulic Auxiliary engine: 522KW Cummins
Emergency Generator: 30KW WEICHAI
Total power: 2437KW
Oil Consumption: 365L/H
Hull Dimension: 50m×8.8m×2.5m
Key Features & Applications
Our dredgers come equipped with horizontal shifting devices, cutter ladder lifting devices, spud devices, and deck cranes. Optional anchoring poles and trolley devices are available. The system creates vacuum through centrifugal pump action for efficient dredging, conveying, and discharging of sand and mud.
Piping Systems
The dredger can be equipped with steel, HDPE, or self-floating pipes for solid discharge work. Customers may provide their own piping or have it custom-made. All pipelines are shipped in 40" HQ containers, and we recommend purchasing spare pipelines.
Contact us for more information about our cutter suction sand dredgers and customized solutions.
